Product name: YF—D870
Category: Engraving Product model: YF-D870 Product brand: yifan Manufacturer: Ninghai Yifan CNC Machinery Co.,Ltd. Price: Negotiation/Telephone Inquiry
Product details
| ITEM | Unit | YF-D870 |
| XYZ axis work schedule | mm | 800*700*300 |
| XYZ position precision | mm | 0.01 |
| XYZ repeat positioning accuracy | mm | <0.005 |
| Table size | mm | 800*700 |
| The biggest processing XZ space | mm | 900*600 |
| Maximun processing speed | mm/min | 8000 |
| The highest spindle seed | r/min | 15000 |
| Spindle power | kw | 8 |
| Maximum working load | kg | 850 |
| The maximum output voltage | v | 380 |
| Machine net weight | T | 4.5 |
| The spindle taper/gripping the handle | BR32 | |
| XYZ largest dimension | mm | 2200*2200*2500 |
| Lubrication system | Adjustable automatic lubricating device | |
| Numerical control system | Taiwan SYNTEC | |
| Servo motor | Japan YASKAWA | |
| screw | Taiwan HIWIN | |
| guide | Taiwan HIWIN |
