ITEM | Unit | YF-G660 |
XYZ axis work schedule | mm | 600*600*300 |
XYZ position precision | mm | 0.01 |
XYZ repeat positioning accuracy | mm | <0.005 |
Table size | mm | 600*600 |
The biggest processing XZ space | mm | 670*550 |
Maximun processing speed | mm/min | 10000 |
The highest spindle seed | r/min | 30000 |
Spindle power | kw | 5.5 |
Maximum working load | kg | 600 |
The maximum output voltage | v | 380 |
Machine net weight | T | 5.5 |
The spindle taper/gripping the handle | | BT30 |
XYZ largest dimension | mm | 2000*2000*2500 |
Lubrication system | | Adjustable automatic lubricating device |
Numerical control system | | Taiwan SYNTEC |
Servo motor | | Japan YASKAWA |
screw | | Taiwan HIWIN |
guide | | Taiwan HIWIN |
